GL Fiber provide double jacket ADSS Track-Resistant Cable is designed for self-supporting applications for cable spans up to 1500m, allowing an easy and cost-effective one-step installation using standard hardware and installation methods.
Track-resistant PE (TRPE) double jacket with additives makes a resistant, durable and easy to strip cable, providing superior protection against UV radiation, fungus, abrasion and other environmental factors. Available for high voltage transmission lines for the following electric field potential ranges: 12 kV to 25 kV and higher than 25 kV up to 400 kV.
The SZ-stranded method for loose tubes and four ripcords ensure a quick and easy mid-span access.
Dielectric central strength member requires no bonding or grounding.
Aramid yarns have an excellent performance against high tension for direct-aerial installations, aerial to duct transitions and can be used for other applications that require added tensile performance such as long duct pulls. No messenger cable is required for installation, and no metallic components are used in ADSS cables. These attributes allow the cable to be installed live-line and in the power space of distribution lines.
Optical fiber type and properties
|
(Item) |
Unit |
Specification |
|
|
G. 652 |
|||
| Mode field diameter |
1310nm |
mm |
9.2 ± 0.4 |
|
1550nm |
mm |
10.4 ± 0.8 |
|
| Cladding diameter |
mm |
125.0 ± 1 |
|
| Cladding non-circularity |
% |
£1.0 |
|
| Core/cladding concentricity error |
mm |
£0.5 |
|
| Coating diameter |
mm |
242 ± 7 |
|
| Coating/cladding concentricity error |
mm |
£12 |
|
| Cable cut-off wavelength |
nm |
£ 1260 |
|
| Attenuation Coefficient |
1310nm |
dB/km |
£0.36 |
|
1550nm |
dB/km |
£0.22 |
|
| Proof stress level |
kpsi |
≥100 |
|
ITU-T G.652 (Other parameters meet standard ITU-T G.652)
(Dimensions of cable constructions)
|
Span （m） |
Fiber count |
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
200 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.2±0.5 |
144 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.2±0.5 |
144 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.2±0.5 |
145 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.5±0.5 |
151 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
14.8±0.5 |
187 |
|
Span （m） |
Fiber count |
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
300 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.3±0.5 |
145 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.3±0.5 |
146 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.3±0.5 |
147 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
154 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
14.9±0.5 |
184 |
|
Span （m） |
Fiber count
|
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
400 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
151 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
152 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
152 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.9±0.5 |
160 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
15.2±0.5 |
195 |
|
Span （m） |
Fiber count |
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
500 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
152 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
153 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.6±0.5 |
153 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.1±0.5 |
163 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
15.4±0.5 |
198 |
|
Span （m） |
Fiber count
|
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
600 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.8±0.5 |
155 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.8±0.5 |
156 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
13.8±0.5 |
157 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.3±0.5 |
168 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
15.5±0.5 |
201 |
|
Span （m） |
Fiber count
|
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
800 |
12 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.0±0.5 |
159 |
|
24 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.0±0.5 |
160 |
|
|
36 |
1+6 |
6 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.0±0.5 |
161 |
|
|
48 |
1+6 |
12 |
2.5±0.1 |
2.8/2.8 |
0.9±0.1 |
1.7±0.1 |
14.4±0.5 |
171 |
|
|
96 |
1+8 |
12 |
2.5±0.1 |
3.4/4.3 |
0.9±0.1 |
1.7±0.1 |
15.8±0.5 |
209 |
|
Span （m） |
Fiber count
|
Structure |
Fibers per tube |
Loose tube diameter (mm) |
CSM diameter /pad diameter (mm) |
Thickness of Inner jacket (mm) |
Thickness of outer jacket (mm) |
Cable diameter(mm) |
Cable weigh (kg/km) |
|
1000 |
12 |
1+6 |
6 |
3.0±0.1 |
3.0/3.0 |
0.9±0.1 |
1.7±0.1 |
15.1±0.5 |
187 |
|
24 |
1+6 |
6 |
3.0±0.1 |
3.0/3.0 |
0.9±0.1 |
1.7±0.1 |
15.1±0.5 |
187 |
|
|
36 |
1+6 |
6 |
3.0±0.1 |
3.0/3.0 |
0.9±0.1 |
1.7±0.1 |
15.1±0.5 |
188 |
|
|
48 |
1+6 |
12 |
3.0±0.1 |
3.0/3.0 |
0.9±0.1 |
1.7±0.1 |
15.5±0.5 |
196 |
|
|
96 |
1+8 |
12 |
3.0±0.1 |
4.1/4.9 |
0.9±0.1 |
1.7±0.1 |
17.8±0.5 |
266 |
Cable performance
| (Item) | (Parameters) | ||||
| Loose tube | Material | PBT | |||
| Color | All colors display | ||||
| Filler | Material | PE | |||
| Color | Black | ||||
| CSM | Material | FRP | |||
| Inner jacket | Material | MDPE | |||
| Color | Black | ||||
| Non-metal reinforced pieces | Material | Aramid yarn | |||
| Outer jacket | Material | AT | |||
| Color | Black | ||||
| Min. bending radius | Static | 12.5 times cable diameter | |||
| Dynamic | 25 times cable diameter | ||||
| Repeating bending | Load：150N;number of cycles:30 No obvious addition attenuation, no fiber break and no cable damage. | ||||
| Tensile performance |
Span |
Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
200 |
12 |
14700 |
6600 |
3670 |
|
|
24 |
14700 |
6600 |
3670 |
||
|
36 |
14700 |
6600 |
3670 |
||
|
48 |
15120 |
6800 |
3770 |
||
|
96 |
17340 |
7800 |
4330 |
||
|
Span |
Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
300 |
12 |
7200 |
3200 |
1700 |
|
|
24 |
7200 |
3200 |
1700 |
||
|
36 |
7200 |
3200 |
1700 |
||
|
48 |
8200 |
3600 |
2000 |
||
|
96 |
9400 |
4200 |
2200 |
||
|
Span |
Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
400 |
12 |
16450 |
7400 |
4100 |
|
|
24 |
16450 |
7400 |
4100 |
||
|
36 |
16450 |
7400 |
4100 |
||
|
48 |
17340 |
7800 |
4330 |
||
|
96 |
19340 |
8700 |
4830 |
||
|
Span |
Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
500 |
12 |
24500 |
11000 |
6120 |
|
|
24 |
24500 |
11000 |
6120 |
||
|
36 |
25800 |
11000 |
6120 |
||
|
48 |
8200 |
11600 |
6440 |
||
|
96 |
28900 |
13000 |
7200 |
||
|
Span |
Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
600 |
12 |
28100 |
12600 |
7000 |
|
|
24 |
28100 |
12600 |
7000 |
||
|
36 |
28100 |
12600 |
7000 |
||
|
48 |
29400 |
13200 |
7300 |
||
|
96 |
32500 |
14600 |
8100 |
||
|
Span |
芯数 Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
800 |
12 |
32500 |
14600 |
8100 |
|
|
24 |
32500 |
14600 |
8100 |
||
|
36 |
32500 |
14600 |
8100 |
||
|
48 |
34300 |
15400 |
8550 |
||
|
96 |
38300 |
17200 |
9550 |
||
|
Span |
芯数 Core |
RTS (N) |
MAT (N) |
EDS (N) |
|
|
800 |
12 |
44500 |
20000 |
11200 |
|
|
24 |
44500 |
20000 |
11200 |
||
|
36 |
44500 |
20000 |
11200 |
||
|
48 |
46100 |
20700 |
1150 |
||
|
96 |
53400 |
24000 |
13300 |
||
| Crush | Short term | 3000N/100mm | |||
(Environmental performance)
|
(Item) |
(Standard) |
(Parameters) |
|
Operation temperature |
IEC 60794-1-2 F1 |
-20℃～+60℃ |
(Drum)
|
(Cable type) |
(Drum) |
||||
|
Height (mm) |
Width (mm) |
Inner diameter (mm) |
Length (km) |
Drum type |
|
|
ADSS-12、24、36、48-200m |
1050 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-200m |
1100 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-12、24、36、48-300m |
1050 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-300m |
1150 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-12、24、36-400m |
1050 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-48-400m |
1100 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-400m |
1150 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-12、24、36、-500m |
1050 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-48-500m |
1100 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-500m |
1150 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-12、24、36、-600m |
1050 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-48-600m |
1100 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-600m |
1200 |
760 |
500 |
2 |
Iron wood drum |
|
ADSS-12、24、36、48-800m |
1100 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-800m |
1250 |
760 |
500 |
2 |
Iron wood drum |
|
ADSS-12、24、36/48-1000m |
1150 |
760 |
500 |
2 |
Plywood wood drum |
|
ADSS-96-1000m |
1400 |
760 |
650 |
2 |
Iron wood drum |
